DIG06 Series | 6W 8:1 DC-DC Converter

6W 8:1 Ultra Wide Input DC-DC Converter (DIP-24)

DIG06 Series

Industrial standard DIP-24 package

8:1 Wide input range

High efficiency up to 85%

No external components required internal filtering

Power saving load for high efficiency at light load

Overload protection & UVLO

3000Vdc I/O isolation

Low cost

ABES technology co., ltd.

INPUT
Item		Conditions
Voltage Range		9~75V
Surge Voltage (100ms max.)		9-75 Vin models: 100Vdc
Filter		Pi Network
Protection		Fuse recommended (see page 7 )
OUTPUT
Item		Conditions
Voltage Accuracy		±2% max.
Rated Power		6W
Ripple & Noise¹		100mVp-p max.
Line Regulation²		±0.5%
Load Regulation³		±0.5%
Cross Regulation		±5%		Dual：asymmetrical load 25%/100% FL
Switching Frequency		300Khz typ. (PWM)
PROTECTION
Item		Conditions
Short Circuit		Protection type: continuous, recovery
Overload		110%~230%
		Protection type: recovers automatically after fault condition is removed
Over Voltage		Clamp by TVS diode
ENVIRONMENTAL
Item		Conditions
Cooling		Free-air convection
Working Temperature		-40~ +85°C (refer to“Derating Curve”)
Case Temperature		+105 °C max.
Working Humidity		5% ~ 95% RH non-condensing
Storage Temp., Humidity		-55 ~ +125°C, 10 ~ 95% RH non-condensing
Temperature Coefficient		±0.05% / °C
Soldering Temperature		1.5mm from case of 3~5 sec./265°C(max.)
Vibration		10~500Hz, 2G 10min./1cycle, period for 60 min. each along X, Y, Z axes
SAFETY & EMC
Item		Conditions
Isolation Voltage		I/P-O/P：3KVdc
Isolation Resistance		I/P-O/P: 1000M Ohms / 500VDC / 25°C / 70% RH
Isolation Capacitance		1000pF typ.
EMC Emission		Parameter	Standard		Test Level / Note
		Conducted	EN55032(CISPR32)		N/A
		Radiated	EN55032(CISPR32)		Class A with external filter
					Class B with external components
EMC Immunity EMC Immunity		Parameter	Standard		Test Level / Note
		ESD	BS IEC 61000-4-2		Air ±8KV, Contact ±4KV
		Radiated Susceptibility	BS IEC 61000-4-3		3V/m
		EFT/Burst	BS IEC 61000-4-4		±0.5KV
		Surge	BS IEC 61000-4-5		Line-Line ±0.5KV
		Conducted	BS IEC 61000-4-6		3Vrms
		Magnetic field immunity	BS IEC 61000-4-8		1A/m
OTHERS
Item	Conditions
MTBF⁴	>400,000Hours
Weight	17.5g typ.
Dimension(LWH)	31.8mm20.3mm12.2mm
Case Material	Non-conductive plastic
Note: 1 Ripple & noise are measured at 20MHz BW with 1uF ceramic capacitor connect to the output pins. 2 High line to low line. 3 Load regulation is for output load current change from 5% to 100%. 4 MIL-HDBK-217F @25 °C, Ground Benign. *All specifications are measured at Ta=25°C, humidity < 75%, nominal input voltage, and rated output load unless otherwise specified.

ABES technology co., ltd.

MODEL SELECTION TABLE:
Model Number	Input				Output		Efficiency (%)	Capacitor Load (Max.)
	Voltage (VDC)		Current (mA)		Voltage (VDC)	Current (mA)
	Nominal	Range	No Load	Full Load	Voltage (VDC)	Current (mA)
DIG06-W48S3.3(W)	48	9-75	5	268	3.3	0~1500	77	1800uF
DIG06-W48S05(W)			5	309	5	0~1200	81	1000uF
DIG06-W48S09(W)			7	301	9	0~667	83	680uF
DIG06-W48S12(W)			7	294	12	0~500	85	470uF
DIG06-W48S15(W)			8	294	15	0~400	85	220uF
DIG06-W48D05(W)	48	9-75	7	309	±5	±0~600	81	±470uF
DIG06-W48D12(W)			9	294	±12	±0~250	85	±100uF
DIG06W48D15(W)			10	294	±15	±0~200	85	±100uF

The ABES DIG06 Series is a 6W Isolated DC-DC Converter specifically engineered for high-reliability industrial environments. Housed in a standard DIP-24 package, it features an exceptional 8:1 ultra-wide input range, effectively simplifying system design and reducing inventory requirements for different voltage systems.

This series offers up to 3000Vdc I/O isolation, significantly enhancing system safety and noise immunity. The DIG06 delivers 85% efficiency and incorporates power-saving technology to maintain high stability even under light load conditions. With internal filtering and comprehensive protection mechanisms (Overload and UVLO), it is the perfect power solution for industrial automation, distributed power architectures, and critical data communications.
